Image device | 1/4-inch color CMOS PC1030 |
TV system | NTSC |
Effective pixels | 628 × 582 pixels |
Sensing area | 5.78mm × 4.19mm |
Sync system | Internal |
Resolution | 420 TV lines |
Minimum illumination | 3Lux/F1.2(0 lux when infrared LED on) |
Lens | 1.7mm/170deg |
Night vision range | 6m |
S/N ratio | More than 48db |
Electronic shutter | 1/60 - 1/15000 seconds |
Video output | RCA connector,1.0vp-p,75ohm |
Current consumption | 130mA |
Power supply | 12V DC |
Operating temperature | -20 to 50 degrees ccentigrade,RH95% max. |
Storage temperature | -30 to 60 degrees ccentigrade,RH95% max. |
Other items | Automatic white balance ,AGC and BLC |
Size | ￠18.5mm * 28mm |
Wight | 70g |
